Description
The DS S005 is a specialized servo motor designed for applications that prioritize lightweight construction, compact size, and precise control. This servo stands out for its utilization of a coreless motor and plastic gears, making it well-suited for projects where weight, size, and accuracy are crucial considerations.
Lightweight Design: Engineered to be lightweight, the servo is ideal for applications where minimizing weight is essential, such as in small-scale models, drones, and other lightweight devices.
Coreless Motor Technology: The coreless motor design enhances the servo's efficiency, response time, and longevity by reducing inertia, making it particularly suitable for applications requiring rapid and precise movements.
Plastic Gear Train: The servo features a gear train made of durable plastic, providing a balance between weight and cost-effectiveness. While not as robust as metal gears, plastic gears are well-suited for lightweight applications.
Compact Form Factor: With a small physical footprint, the 8g Plastic Gear Coreless Servo is designed to fit into applications with limited space and stringent weight requirements.
High Torque for Size: Despite its small size, the servo is designed to provide a sufficient amount of torque, allowing it to control various lightweight mechanisms effectively.
Digital Control: Utilizing digital control technology, this servo provides improved accuracy, precision, and responsiveness compared to traditional analog servos.
Plug-and-Play Integration: Many servos of this type are designed for easy integration into microcontroller-based systems, allowing for quick setup and operation.
| Operating Voltage: |
4.8-6V |
| Rated Voltage: |
6V |
| Standby Current: |
≤20 mA |
| No Load Current: |
≦90mA |
| No Load Speed: |
0.12sec/60° |
| Rated Torque: |
≥0.23kgf·cm |
| Rated Current: |
≦230mA |
| Stall Current: |
≦900mA |
| Stall Torque(static): |
≥1.8kgf·cm |
| Weighting Torque(dynamic): |
≥0.9kgf·cm |
| Rotating Direction : |
（2000-1000us）-CW |
| Pulse Width Range: |
500-2500us |
| Neutral Position: |
1500us |
| Operating Travel Angle: |
180° ±10° (500~2500 us) |
| Mechanical Limit Angle: |
210° |
| Return Angle Deviation: |
≤ 2° |
| L&R Angle Deviation: |
≤ 7° |
| Dead Band Width: |
≤ 5us |
| Operating Temperature Range: |
-10℃~+50℃, ≤90%RH; |
| Storage Temperature Range: |
-20℃~+60℃, ≤90%RH; |
| Weight: |
8± 0.3g |
| Case Material: |
ABS |
| Gear Set Material: |
Plastic gear |
| Motor Type: |
coreless motor |
